Spinning Basket Reactor

Spinning Basket Reactor
Spinning Basket Reactor
Product Code : QCRE - 22
Brand Name : Quality Engineers
Price And Quantity
  • Minimum Order Quantity
  • 1
  • Unit of Measure
  • Unit/Units
Product Description

SPINNING BASKET REACTOR

(Compressed Air Feed System)



Technical Description:

Catalytic Reaction:

                                Any catalytic liquid-liquid or liquid-gas reaction involving the use of a catalyst placed in basket can be studies in this set-up. Kinetic parameter of a specific reaction can be estimated & parametric studies

can be conducted. The set-up consists of a reactor centrally having one spinning basket derived through a variable speed motor. The metered flow of reactant from feed tank is fed to the reactor at the bottom. The set-up can be used as batch wise of as continuous type. Sampling points are provided for analysis. Port connection for gas

inlet is provided at the bottom of the reactor.



LEARNING OBJECTS/EXPERIMENTATION:

Ø  To determine the kinetic parameters for a given reaction.



REQUIRMENT FOR OPERATION:

Ø  Compressed air supply at 1 Bar.

Ø  Water Supply.

Ø  Floor Drain.

Ø  Power Supply : 0.5 kW, Single Phase.

Ø  Instruments, Laboratory Glassware and Chemicals required for analysis as per the system adopted.



TECHNICAL SPECIFICATION:

Ø  Reactor vessel: material stainless steel

                       Effective volume :1000ml

Ø  Basket: material stainless steel,capacity-10ltrs.

Ø  Drive for basket: dc motors with thyristor controlled dc drive for variable speed.

Ø  Packing: catalyst

Ø  Feed tank: material stainless steel,capacity-10 ltrs.

Ø  Flow measurement: rota meter

Ø  Pressure regular: operating range 0-2kg/cm2

Ø  Pressure gauge :bourdon type 0-2kg/cm2 standard make

Ø  Receiver: material stainless steel, capacity 10ltrs.

                Stainless steel pvc

Ø  Piping: magnetic pump of poly propylene to circulate hot

Ø  Hot water circulation: water maximum working temp.85o c made of stainless steel, double wall insulated

(in outer jacket)        with ceramic wool. Capacity: 10-15 ltrs.

Ø  Hot water tank: nichrome wire heater 750-1000 w approx.



Control Panel:

Ø  Standard make on/off switch, Mains Indicator etc.



Scope of Delivery:

Ø  1 Self-contained “spinning basket reactor” Apparatus

Ø  1 Instruction Manual consisting of experimental procedures, block diagram etc.





Trade Information
  • FOB Port
  • Chandigarh
  • Payment Terms
  • Cash Advance (CA), Cash in Advance (CID)
  • Supply Ability
  • 10 Per Month
  • Delivery Time
  • 30 Days
  • Sample Available
  • Yes
  • Sample Policy
  • Sample costs shipping and taxes has to be paid by the buyer
  • Packaging Details
  • Material will be packed in safe carton
  • Main Domestic Market
  • All India
  • Certifications
  • ISO 9001 : 2015 Certified
