Pin On Disc Wear Apparatus

Pin On Disc Wear Apparatus
Pin On Disc Wear Apparatus
Product Code : QTOM -12
Brand Name : Quality Engineers
Price And Quantity
  • Minimum Order Quantity
  • 1
  • Unit of Measure
  • Unit/Units
Product Description

PIN ON DISC APPARATUS

Technical Description:
Pin on Disc Wear Test Rig is designed to study friction and wear characteristics in sliding contacts. Sliding occurs between a stationary pin and a rotating disc. Normal load and wear track diameter can be varied. Tangent is frictional force and wear are monitored with electronic sensors. This test rig is suitable for demonstration of wear and friction properties.

LEARNING OBJECTS/EXPERIMENTATION:
Ø Continuously variable wear Track
Ø Display of wear and frictional force.
Ø Pre-settable test duration.

REQUIRMENT FOR OPERATION:
Ø Mercury: 250 ml.


TECHNICAL SPECIFICATION:
Ø Wear Disc
Diameter                                 : 100mm
Thickness                                : 6mm minimum&8mmmaximum
Ø Pin Diameter                           : 6mm
Ø Length                                    : 25 mm
Ø Wear Track Diameter               : 50mm minimum & 80mm maximum (Variable)
Ø Disc Speed                              : 300 RPM
Ø Normal Load                            : 5 minimum & 30 maximum (In steps of 5N)
Ø Frictional Force                        : 0 minimum& 30maximum
Ø Wear Range                             : 0mm minimum & 2mm maximum
Ø Preset Timer                           : 1 minute minimum & 9999 maximum
Ø Power                                      : 230 V, 1 Ph, 50Hz, 500 VA
Ø  An ENGLISH instruction manual consisting of experimental procedures, block diagram etc. will be provided along with the Apparatus
Ø  Thewholeset-upiswelldesignedandarrangedonarigidstructurepaintedwithindustrialPUPaint.

Control Panel:
Ø  Standard make on/off switch, Mains Indicator etc.

Scope of Delivery:
Ø  1 Self-contained “PIN ON DISC APPARATUS” Apparatus
Ø  1 Instruction Manual consisting of experimental procedures, block diagram etc.

Trade Information
  • FOB Port
  • Chandigarh
  • Payment Terms
  • Cash Advance (CA), Cash in Advance (CID)
  • Supply Ability
  • 10 Per Month
  • Delivery Time
  • 30 Days
  • Sample Available
  • Yes
  • Sample Policy
  • Sample costs shipping and taxes has to be paid by the buyer
  • Packaging Details
  • Material will be packed in safe carton
  • Main Domestic Market
  • All India
  • Certifications
  • ISO 9001 : 2015 Certified
