Heat Pipe Demonstrator

Heat Pipe Demonstrator
Heat Pipe Demonstrator
Product Code : HT-03
Brand Name : QUALITY ENGINEERS
Price And Quantity
  • Minimum Order Quantity
  • 1
  • Unit of Measure
  • Unit/Units
Product Description
Our company offers best quality Heat Pipe Demonstrator at the most competitive market price. These demonstrators are manufactured in compliance with the industry laid norms and parameters using finest quality metal. Owing to the corrosion resistance, easy installation, hassle-free operation and longer functional life, these demonstrators are extensively demanded around the globe.

Description:
  • It is a super-conducting device and involves the transfer of heat by boiling and condensation of a fluid and hence transfer of heat takes place under nearly isothermal condition. In this apparatus the comparison of heat pipe with the copper pipe as good conductor of heat and with the stainless steel pipe as same material of construction is made. It consists of three identical cylindrical conductors in respect of geometry.
  • One end of these is heated electrically while there are small capacity tanks acting as heat sinks at the other end. The unit consists of a heat pipe, a copper pipe and a stainless steel pipe.
  • The performance of the heat pipe as a super-conducting device can be studied well in terms of the temperature distribution along the length at a given instant and can be compared with other two members. Nearly isothermal temperature distribution and fast rise of temperature in heat sink tank reveals the heat pipe superiority over the conventional conductors.
Experimentation:
  • To demonstrate the super thermal conductivity of Heat Pipe and to compare its working with best conductor i.e. Copper pipe & Stainless steel pipe as same material of construction.
  • To plot the temperature v/s time response of pipes.
  • To plot the temperature distribution along the length of pipes
Utilities required:
  • Electricity Supply : 1 Phase, 220 V AC, 4 Amp.
  • Table for set-up support.
Technical Specifications:
  • Pipes1ST: Heat pipe made of stainless steel
  • Pipes 2ND: Made of copper
  • Pipes 3 RD: Made of Stainless steel
  • Size: 32mm dia, 350 mm length (Approx.)
  • Heat Sink: Material Stainless steel.
  • Working fluid in heat pipe: Distilled water
  • Heaters: Nichrome Wire Band Type
  • Digital Voltmeter: 0-300 Volts.
  • Digital Ammeter: 0-2 Amp.
  • Variac: 0-230 V, 4 Amp.
  • Digital Temp. Indicator: 0-2000 C, with multi-channel switch
  • Temperature Sensors: RTD PT-100 type
  • Instruction Manual: An ENGLISH instruction manual will be provided along with the Apparatus
Trade Information
  • FOB Port
  • Chandigarh
  • Payment Terms
  • Cash Advance (CA)
  • Supply Ability
  • 10 Per Month
  • Delivery Time
  • 30 Days
  • Sample Available
  • Yes
  • Sample Policy
  • Sample costs shipping and taxes has to be paid by the buyer
  • Packaging Details
  • Material will be packed in safe carton
  • Main Domestic Market
  • All India
  • Certifications
  • ISO 9001 : 2015 Certified
