Flow Through Helical Coil
- Minimum Order Quantity
- Unit of Measure
Helical coils are used for heating or cooling in process tanks. When a fluid flows through a curved tube, centrifugal force acting upon the various elements of fluid moving with different velocities causes secondary circulation. Secondary flow results in higher heat transfer characteristics. Further, secondary flow stabilizes the laminar flow leading to a higher critical Reynolds number for transition from laminar to turbulent flow.
Ã To determine the critical Reynolds number of a fluid flowing through the coil.
Ã To compare Pressure drop in helical coil with that in a straight pipe of same length, inside diameter and surface roughness.
Required for Operation:
Ã Electricity 500 watts, 220 V, 1 Phase.
Ã Floor Area 1 m x 2 m.
Ã Helical Coil : Material Stainless Steel Dia â 12â
Ã No. of Turns : 14
Ã Coil Tube Dia : OD 21mm, ID 16mm (Approx.)
Ã Sump Tank : Material Stainless Steel, Capacity 50 Ltrs.
Ã Water Circulation : FHP Pump, Crompton/Sharp make.
Ã Pressure Drop Measurement: By Manometer
Ã Flow measurement : Rotameter.
Ã Piping : GI and PVC
Ã Standard make on off switch, Mains Indicator etc.
Scope of Delivery:
Ã 1 Self-contained âFLOW THROUGH HELICAL COILâ Apparatus
Ã 1 Instruction Manual consisting of experimental procedures, block diagram etc.
- FOB Port
- Payment Terms
- Cash Advance (CA), Cash in Advance (CID)
- Supply Ability
- 10 Per Month
- Delivery Time
- 30 Days
- Sample Available
- Sample Policy
- Sample costs shipping and taxes has to be paid by the buyer
- Packaging Details
- Material will be packed in safe carton
- Main Domestic Market
- All India
- ISO 9001 : 2015 Certified
