Coriolli's Component of Acceleration

Coriolli's Component of Acceleration
Coriolli's Component of Acceleration
Product Code : QTOM - 08
Brand Name : Quality Engineers
Price And Quantity
  • Minimum Order Quantity
  • 1
  • Unit of Measure
  • Unit/Units
Product Description



“CORIOLLIS COMPONENT OF ACCELERATION APPARATUS WITH DIGITAL RPM INDICATOR”

DESCRIPTION:
The set-up is designed to study Coriolli's Component of Acceleration of a slider crank mechanism. Here the mechanical slider system is replaced by a continuous stream of water flowing through a steady rotating pair of tubes. These tubes can be rotated at various speeds by using a swinging field motor which also acts as dynamometer. A Perspex window on top of the tank gives clear view of the process and prevents splash of the water over the side of the tank. The dynamometer continuously measures torque applied to the rotating tubes. The equipments is self contained, water re-circulating, provided with its own speed control unit and water circulating pump.



    EXPERIMENTATION:
Ø  To determine Coriolli's Component of Acceleration at various speeds of rotation and water flow rates

UTILITIES REQUIRED:
Ø  Water Supply.
Ø  Drain.
Ø  Electricity supply: 220 V, Single Phase, 0.5 kW.

TECHNICAL DETAILS:
Ø  Water Tank: Made of Stainless Steel
Ø  Rotating Arms: 9mm/6mm orifice diameter, Length 300 mm.
Ø  Rota meter: 250 to 2500 LPH
Ø  Electric Motor: Swinging field, Variable speed.
Ø  Pump: FHP for water circulation.
Ø  Control Panel Comprises of: RPM measurement: RPM Indicator with Proximity sensor.
Ø  Speed Control Unit.
Ø  Standard make On/Off Switch, Mains Indicator, etc.
Ø  Instruction Manual: An ENGLISH instruction manual will be provided along with the Apparatus
Ø  The whole set-up is well designed and arranged in a good quality painted structure.

CONTROL PANEL:
Ø  Standard make on/off switch, Mains Indicator etc.

SCOPE OF DELIVERY:
Ø  1 Self-contained “CORIOLLIS COMPONENT OF ACCELERATION APPARATUS WITH DIGITAL RPM INDICATOR” Apparatus
Ø  1 Instruction Manual consisting of experimental procedures, block diagram etc.
